MSD 8000 MSD PRO 600 CDI

Eight outputs of up to 680 mJ of energy All necessary wiring harnesses included Continuous 600 mJ operation without risk of failure from overheating High-efficiency Alternating Current (AC) power delivery means less voltage draw from your battery or charging system Over 50 Kilovolts output voltage when used with MSD suggested coils Spark duration of greater than 300 microseconds 6 Volts minimum required for starting and running 12 Volts minimum required for 600 mJ opereation Maximum Operating Voltage 22V Direct Plugin to Holley EFI systems Compatible with most EFI systems, including 5V or 12V drivers Plugin interface with MSD Power-Grid, Davis Profiler and OEM LS-style coil harness Reverse Battery Protection Protection against shorted or open coils, and over temperature Diagnostic LEDs help troubleshoot issues should they arise On the fly Power Output selection wire, selectable between low power and high power operation Fits most coil-per-plug engines up to eight cylinders (Including four and six cylinders) Additional CAN based features when used with Holley EFI - See addendum below Approved for NHRA Pro Mod Class
