Earthquake Sound EQ-4000BT v2 — 9V Max RMS 4-Band Equalizer with Bluetooth™ (1/2 DIN)

Compact 1/2 DIN four-band equalizer with Bluetooth™ connectivity and a 9 Volt RMS output. The EQ-4000BT v2 provides precise tonal shaping plus subwoofer control for automotive audio systems. Electrical Specifications: - Operating Voltage: 10.5–16VDC - Idle: 280 mA - Recommended Fuse Size: 1 Ampere - Input Sensitivity: 100 mVrms up to 14 Vrms - Input Impedance: 8 kOhm up to 10.2 kOhm - Output Impedance: Sub Channel: 510 Ohm; Front & Rear Channels: 6.3 kOhm - Output Level: Sub Channel 5 Vrms @ 0.1% THD; Front & Rear Channels 4 Vrms @ 0.1% THD - THD @ 3 Volts Output: 0.05% - Frequency Response: 15Hz–34kHz @ -3dB - Sub Frequency Control Range: 35–120Hz @ -3dB, 18dB/Oct. - Sub Upper Cut Off Frequency: 100Hz - Signal-to-Noise Ratio: 68dB Center Frequencies: 92dB Control Range: 150Hz, 550Hz, 2.5kHz, 15kHz - Channel Separation: 30–40dB (12 O’clock is bypass position) Features and Controls: - 4 Adjustable Bands of Equalization (-12dB to +12dB) - 4 Input Sources: RCA, AUX, mini jack, Bluetooth™ - 3 Stereo RCA Outputs: Front, Rear, Sub - 9 Volt RMS Output - Input Gain Control - Media Player Ready - Fully Retractable Controls for a clean installation - Front panel MAIN/AUX control and Front panel Bluetooth ON/OFF control - Volume level control and Subwoofer level control - Subwoofer frequency control - Fader action control - Blue background LED for panel illumination Physical and Accessories: - Din Size: 1/2 Din - Mounting hardware and 1A fuse included - 3 pin plug-in PCB screw terminal block connector included
