DAE DDM730P, RS485, 120/240V kWh Meter, 100A, 1P3W (2 hot wires, 1 neutral), Internal CT, 60 Hz, Pass Through

DDM730P monitors the whole electrical panel (2 hot wires, 1 neutral) for both 120V circuits and 240V circuits. It can also monitor 240V circuit only. But it cannot monitor 120V circuit only since the meter is powered by 240V. Please choose DAE DEM720-1P or DDM710 for monitoring 120V circuit only. DAE Cloud Metering (2nd picture) available with DAE CC2030 KIT Gateway.

CC2030 will collect energy data from DAE electrical meters and send them to Cloud Server through Ethernet. With PC, cell phone or tablet, landlords or property managers can get access to real time data, monthly kWh and billing reports to their tenants. TOU (Time of Use) billing reports are also available. No IT guy is required. Just connect wires as per picture 5 or see video & ready to go.

For existing building, hard to draw cable between electric meter (close to electric panel) and CC2030 (close to your router), please choose 1 CC2030 KIT + 2 WSC500A RF Converters to connect electric meter and CC2030 wirelessly(3rd picture). Conforms to International Standard IEC62053-21 and IEC62052-11.

For UL/cUL listed and California CTEP approved electric meters, please refer to DAE Polaris 1500 series like DAE P153-200-S KIT. Indoor use only, DAE B1725 watertight enclosure is available for outdoor use. Factory Calibration Certificates available. DAE Controls LLC is a Minority Business. Please feel free to get the NMSDC Minority Supplier Certificate from DAE Controls Website.

Like our customer Devonshire Mall in Windsor, Canada, if connecting DAE meters with RS485 communication like DDM730P to your system, you will be able to collect the metering data through Modbus RTU/RS485 protocol. In DAEControl com/Resource/manuals, you will find the Modbus Reference. Alternatively, you can contact DAE Controls LLC for the Modbus Reference.
