Eugene Color 48MP Camera Accessories sku-11922573968

The Eugene Color 48MP industrial video microscope camera is listed under Camera Accessories for repair, soldering and inspection. SKU: sku-11922573968. It has a 48 megapixel sensor, HDMI and USB output, and a USB2.0 two-output model designation. Output frame rate is 1920*1080 at 60F/S.

It saves MOV video at 4K (25fps), 2K (30fps), 1080P (60fps) or 720P (60fps); recording 4K or 2K requires an SDHC class10 TF card. The TF card interface supports up to 32G. Image settings are 48M 8000X6000, 38M 7168X5376, 26M 5888X4416, 20M 5120X3840 and 16M 4608X3456. Settings include Chinese or English language, mirroring, 50Hz or 60Hz frequency, and 16:9, 16:10 or 4:3 monitor ratios.

Grid options include 15 horizontal lines, 15 vertical lines, a central scale line, custom colors and size. Power supply: 5-12V 1A. The 1-130X C-mount lens has a 50mm-1000mm working distance, a 1 : 15 zoom ratio and magnification from 0.13-2X, or about 1-130X on the display. Field of view ranges from 4.2mm*2.4mm at maximum magnification to 130mm*70mm at minimum magnification.

The lens measures 30mm in diameter and 99mm in length. The camera supports live HDMI and USB viewing, TF (microSD) recording and use with C-mount accessories and cantilever stands.
