X1009 PCIe 5-Port SATA3.0 Expansion Board for 5 5B — DC12V Powered, Up to 5Gbps

The X1009 is a PCIe expansion board that adds five SATA3.0 ports to your 5 5B, enabling connection of up to 5 high-capacity storage devices at once. SATA3.0 interfaces support transfer rates up to 5Gbps to deliver fast data throughput and expand the storage capability of your 5 5B. Power is provided via a standard DC12V input on the board. X1009 includes a high-efficiency converter to supply power to both the 5 5B and attached PCIe devices simultaneously. The card supports 5 hard disks in total. Tested configuration: 4x3.5‘ HDDs and 1x2.5’ Hard Disk, with the measured current requirement around 6A.
