WVC-700W 700W Solar Grid-Tie Microinverter IP65 Waterproof DC-to-AC 110V (US Standard Plug)

Overview: The WVC-700W is a 700W, 110V solar grid-tie microinverter housed in a silver aluminium alloy enclosure. Designed for outdoor use with an IP65 waterproof rating and self-cooling operation, it supports automatic identification and connects to PV strings with a US standard plug. Electrical Input - Maximum Input DC Voltage: 54V - Peak Power Tracking Voltage: 22-45V - Operating Voltage Range: 17-50V - Min/Max Start-up Voltage: 22-50V - Maximum DC Short Circuit Current: 40A - Maximum Input Operating Current: 30A - Number of Circuit Connections Per String: 6 Output and Performance - Output Peak Power: 700watt - Rated Output Power: 650watt - Rated Output Current: 6.36A - Rated Voltage Range: 80-160VAC - Rated Frequency Range: 57-62.5Hz - Power Factor: ＞99％ - Static MPPT Efficiency: 99.5% - Maximum Output Efficiency: 91.2% - Night Time Power Loss: <1W - Total Flow Distortion: <5% Communication and Power Handling - Communication Mode: Power Line Carrier - Power Transmission Mode: Reverse Transmission, Load Priority Environmental and Mechanical - Operating Temperature Range: ﹣40℃~60℃/﹣40℉~140℉ - Waterproof Rating: IP65 - Cooling Method: Self-cooling Dimensions & Weight - Product Size: 21.3*5.8*25cm/8.39*2.28*9.84inch - Package Size: 34*24*11.5cm/13.39*9.45*4.53inch - Net Weight: 1.63kg/3.59lbs - Gross Weight: 2.48kg/5.47lbs Other Details - Model: WVC-700W - Color: Silver - Material: Aluminium Alloy - Power: 700W - Voltage: 110V - Plug Type: US Standard Package Contents - 1* Solar Grid Tie Micro Inverter - 1* Power Cord - 1* English Manual - Other Accessories for Installation
