Weight Indicator Metering Belt Scale Display Conveyor Weight Belt Weighing Controller Instrument

Weight Indicator Metering Belt Scale Display Conveyor Weight Belt Weighing Controller Instrument Main functional parameters Incremental digital PID control can improve the control accuracy and inverse Should speed, and reduce system adjustment fluctuation Source: 24V dc Power consumption: 10 W Working temperature: from5 "C to 65 "C(137 'F to23 F) Humidity: no more than 90% relative humidity (no condensation water) Weight: 1.5 kg of material Applicable sensor type: all resistance strain type weighing sensors Sensor input voltage:5V + 1- 5% dc supply up to 500 mm An electric current .

Input sensitivity: 0.3 mesh V/grid ~ 0.3mV/grid Input impedance: when DC 500V, the impedance between each terminal can not be small In the100mQ Adjustable zero voltage range: 0.3mV ~ 15.0mV Effective input voltage range: 0.3mv ~ 30.0mV Temperature coefficient: S(reading of 0.0008% or less + 0.3 degrees)/ "C Nonlinear error: <0.001 5% less than full scale Sampling method: delta- sigma method Sampling rate: up to 200 times per second
