Thermal Imaging Camera, Infrared Thermal Imager Resolution 160 X 120 Handheld PCB Circuit Industrial Test Temperature Thermal Camera PC Image Analysis

Infrared Thermal Imager Resolution 160 x 120 Handheld PCB Circuit Industrial Test Temperature Thermal Camera PC Image Analysis Product parameters: Infrared resolution:160*120 Infrared response band:8 to 14um Cell size:12um NETD:<=50MK@25C,@F/1.1 Lens focal length:3.2mm IF0V:3.75mrad Field angle:35*27 Focus mode:Free focus Temperature measurenent range;-20 to 550 Measurement accuracy:+-2 Temperature measurement resolution:0.1C Temperature measurement mode:Center point/hou and cold spot tracking Color palette:Rainbow,iron oxide red,cold color,black&whitewhiteblack Emissivity settingAdjustable from 001 to 100 Thermal imaging frame rale:<=25Hz Visible light resolution:640*480 Display size:2.8-inch Image display mode:Infrared/visible light/dual light fusion Lighting system:LED fill light Device storage:Built-in 4G emmc(user available storage space is about 3G Storage image/Video Format:JPG/MP4 Image/Video export method:USB connection to computer export Image analysis function:Support offline analysis on PC Battery Type:Removable Rechargeable Lithium Battery(18650 Battery capacity:2200mAh Working time:2 to 3 hours Power interface:Micro USB Power configuration:5 minutes/20 minutes/no automatic shutdown Work temperature:-10 to +50 Storage temperature:-20 to+60 Relative humidity:10% to 85% RH Product weight:389g Product size:96*72*226mm Related Products: thermal camera,thermal imager,thermal imaging camera,infrared thermal imager,thermal imaging,infrared camera,infrared thermal imager camera,thermal vision,infrared thermometers,infrared water leak detector,thermal gunthermal imagers,infrared thermometer gun,infrared thermometersYou may also like Thermal Imaging Camera, Infrared Thermal Imager 256*192 Pixel Temperature -20°C~550°C Thermal Imaging Camera Thermometer For Repair.
