TARAMPS AUDIOMIXERT0302 Echo FX Sound Table 3-Channel Car Audio Mixer with LED Light in White Red Colorful With illuminated Knobs and Improved Adjustments

The T0302 FX mixer combines exceptional quality with sophisticated design. With illuminated knobs and improved adjustments, including the Echo Effect, this mixer will take your sound system to the next level. The T0302 FX is available in three lighting versions to meet the most varied styles: White, Red and Colored. Whatever your preference, youll get a visually stunning experience and impeccable sound performance. TECHNICAL INFORMATION FREQUENCY RESPONSE : 2Hz 76KHz TOTAL HARMONIC DISTORTION : <0,009% T.H.D. SIGNAL TO NOISE RATIO : 112dB FREQUENCY RESPONSE -3DB PT : 2Hz 76KHz TOTAL HARMONIC DISTORTION PT : <0,009% T.H.D. SIGNAL-TO-NOISE RATIO SNR PT : 112dB INPUT SENSITIVITY Channel 1 = Mic XLR Min: 500mV Max 7mV Line TRS Min : 620mV Max 7.6mV Channels 2 & 3 = Line TRS/RCA Min : 2.55V Max: 60mV 4 EQUALIZATION BANDS PER CHANNEL High 15dB 18KHz Mid High 15dB 2.4KHz Mid Low 15dB 240Hz Low 15dB 30Hz INPUT IMPEDANCE Channel 1 = Mic XRL : Unbalanced 4K Ohms / Balanced 8K Ohms Line TRS : Unbalanced 8.5K Ohms / Balanced 17K Ohms Channels 2 & 3 = Line TRS : Unbalanced 10K Ohms Line RCA : Unbalanced 10K Ohms ECHO FX TIME / ECHO FX REPEAT : 50 350ms 1 12 repetitions OUTPUT IMPEDANCE : Main Out P10/RCA : 47R Aux Out P10/RCA : 47R MAXIMUM OUTPUT LEVEL : Main Out P10/RCA : 18 dBu/6.3Vac Aux Out P10/RCA : 18 dBu/6.3Vac POWER SUPPLY VOLTAGE POWER : 9 16 VDC MAXIMUM CONSUMPTION : 470 mA REMOTE INPUT REM CONNECTOR : 9 16 VDC REMOTE OUTPUT REM CONNECTOR : 100 mA DIMENSIONS W X H X D : 5.28" x 1.65" x 9.66" 145 x 42 x 242 mm WEIGHT : 1.80lb 0.82Kg EAN Multicolored : 7908706600377
