Supermicro X11SDV-8C-TLN2F Mini-ITX Server Motherboard — Intel Xeon D-2141I (8C/16T, 65W) — Single Socket FCBGA 2518, DDR4-2133MHz — Full Warranty

Compact Supermicro X11SDV-8C-TLN2F mini-ITX motherboard built for dense server and appliance use. Powered by an Intel Xeon Processor D-2141I (8-Core, 16 Threads, 65W) on a Single Socket FCBGA 2518 platform. Memory - Four DIMM slots supporting DDR4-2133MHz - Up to 256GB Registered ECC RDIMM or up to 512GB ECC LRDIMM Expansion - 1 x PCIe 3.0 x8 - 1 x PCIe 3.0 x4 - Internal NVMe connectivity via OCuLink Storage - Up to 8 SATA3 (6 Gbps) ports with RAID 0,1,5,10 support - 4 SATA ports available via OCuLink (or the PCIe 3.0 x4 can be used for NVMe) Networking and I/O - Dual LAN with 10GBase-T provided by the Intel SoC (System on Chip) - Rear I/O: 2 x USB 3.0 ports - Internal header: 2 x USB 2.0 ports Power - Supports 12V DC input or standard ATX power input This listing reflects the full specification set of the Supermicro X11SDV-8C-TLN2F and is ideal for compact servers, network appliances, and virtualization hosts.
