SUPERMICRO X10DRC-T4+ Motherboard - Dual socket R3 (LGA 2011) - Intel C612 Chipset - DDR4 2400 MHz - SATA3 E.E. - ATX

Dual socket R3 (LGA 2011) board supporting Intel Xeon processor E5-2600 v4†/v3 family with UPI up to 9.6GT/s, built on the Intel C612 chipset. Memory: 24x DIMM slots supporting up to 3TB† ECC 3DS LRDIMM at up to DDR4-2400†MHz. Expansion: 2 PCI-E 3.0 x16, 3 PCI-E 3.0 x8, and 1 PCI-E 2.0 x4 (in x8) slot. Storage: 10 SATA3 (6Gbps) ports managed by the Intel C612 controller (RAID 0, 1, 5, 10) plus 8 SAS3 (12Gbps) ports via Broadcom 3108 controller (RAID 0, 1, 5, 6, 10, 50, 60). Networking and I/O: Quad LAN with Intel X540 10GBase-T, 5 USB 3.0 (2 rear, 2 front panel, 1 Type-A) and 4 USB 2.0 (2 rear, 2 front panel). Management and reliability features include Integrated IPMI 2.0 with KVM over a Dedicated LAN and SuperCap option support.
