RENOGY RBT12100LFP-M-US Core Battery sku-13078064072

RENOGY RBT12100LFP-M-US is a Multicolor Core Mini lithium iron phosphate battery listed under Engine & Powertrain Replacement Parts (SKU sku-13078064072; UPC 840315230194). The title specifies 12.8V and 100Ah capacity, a 100A BMS and remote-monitoring compatibility. The description lists 106Ah capacity, 6% more usable power and a 300A peak current for 10 seconds.

Its built-in BMS has a low-temperature charging cutoff below 32°F and controls discharge at 100A. Up to 16 batteries can be connected in series or parallel for 20.48kWh of capacity. The impact-resistant housing is intended for RV travel and is described as compatible with Renogy solar controllers and inverters for a 1-hour lead-acid-to-lithium upgrade.

Compared with lead-acid batteries, the listing claims up to 2.3 times the power output, 61% less weight, up to 10 times the lifespan and 81% lower lifetime cost. It also compares its 1356Wh capacity with a standard LiFePO4 battery's 1200Wh and its 300A output for 10 seconds with 280A for 5 seconds. Rated voltage is 12V.

Cycle life is listed as 5000 cycles at 80% depth of discharge and 80% end of life, tested at 0.5C/1C and 25°C. Charge voltage is 14.4V; maximum charge and discharge currents are both 100A. Charging temperature is 32°F to 131°F (0°C to 55°C), and discharge temperature is -4°F to 140°F (-20°C to 60°C). Connection options include series up to 4, parallel up to 8 and combined 4P4S.

The ABS housing has an IP65 protection rating, M8 terminal bolts and a recommended terminal torque of 10 N·m. Dimensions are 10.24 x 6.65 x 8.31 inches (260 x 169 x 211 mm); weight is 23.15 lbs (10.5 kg). The package lists a Core battery and long terminal bolts. A 5-year material and workmanship warranty is included.
