Pneumatic Angle Seat Valve Female thread 304 Stainless Steel Y Type High Temperature Steam Shut-Off Valve

Pneumatic angle seat valve is widely used for frequent start in short time. It has the characteristics of sensitive response and accurate action. When used with solenoid valve, it can accurately control the flow of gas and liquid with pneumatic control. It can meet the requirements of accurate temperature control and dripping liquid. specification: Product name: Pneumatic threaded angle seat valve Body material: CF8 Seat material: stainless steel Stem material: 304/316L stainless steel Applicable medium: water, oil, alcohol, organic solvent, steam, etc. Control gas: neutral gas and air Medium temperature: -10 ~ + 180 Ambient temperature: -10 ~ + 60 Nominal pressure: 1.6Mpa Gas source pressure: 0.3~0.8Mpa Sealing ring material: PTFE Installation: Install as required, with the actuator facing up. Features: large flow, long life, maintenance-free work, high reliability. Wide range of applications: beer and beverage, textile printing, dyeing and bleaching, pharmaceutical and medical equipment, food processing, rubber machinery, organic or inorganic chemicals, cleaning, disinfection, high temperature sterilization, water/sewage treatment. Notice: 1. Package list: Pneumatic angle seat valve*1pc. (By default, 304 material is issued, if needed 316L material, please contact .) 3. Single-acting angle seat valves are normally closed type by default. If you require a single-acting normally open type angle seat valve, Please contact additionally.
