OREI 8X8 HDBaseT HDMI Matrix Switcher Extender — 4K UltraHD 4:4:4 @60Hz, HDR, CEC, IR & RS-232 Control, 8 Receivers + 8 Loop-Outs, CAT5e/6/7, Up to 400 Ft

Professional 8x8 matrix extender with 8 HDMI inputs, 8 HDMI outputs and 8 additional local loop-outs. The unit distributes HDMI sources over a single CAT5e/6/7 LAN cable — rated for runs up to 330 Feet (supports distances up to 400 Ft) — and includes eight receivers for remote displays. Ideal for 4K Blu-ray players, game consoles, media players, satellite receivers, computers, laptops and other HDMI-equipped sources. Video & audio support: Full Ultra HD capability — 4K 60/50Hz@12 bit, 4K @60Hz, 4K 30Hz@24 bit, 60/50Hz@1080p/i, 60/50Hz@720p, 60/50Hz@576p/i, 60Hz@480p/i. All major digital audio formats are supported, including LPCM, DTS HD and Dolby TrueHD. HDMI 2.0 support: 4K@50/60Hz YUV420. HDCP compatibility: Supports HDCP 2.2 and 1.4. Control & management: Front-panel controls, IR remote, RS-232, LAN and Web GUI; includes RS-232 function, Control4 driver support and 4 Channel Bypass. EDID & audio handling: 8 audio outputs and full EDID management. IR system: Wideband IR support (30-60Kh) with IR transport channels that can be forwarded and reversed. HDBaseT technology delivers an uncompressed signal with zero latency — use quality CAT5e/6/STP cable (CAT6 recommended) and avoid converters/adapters for best results. Power over Cable: Supports POE so only a power adapter at the transmitter end is required. Construction & compliance: Rugged metal chassis for efficient heat dissipation; compact, rack-friendly form factor and full HDCP compliance. Professional OREI support with 1 Year Warranty. Package contents: Instruction Manual, 1x HDMI Extender Matrix, 8x HDMI Receivers, 1x 100-240V Power Adapter, 9x IR-Receiver Cables, 9x IR-Blaster Cables, 1x HDMI Matrix Remote, 18x Mounting Ears, 1x RS-232 Cable, 8x Phoenix Connectors. Note: This unit requires only one power adapter to operate.
