LCR Benchtop Digital Bridge 100kHz-1MHZ Desktop LCR Tester Meter Capacitance Resistance Impedance Inductance Measure ,Accurate and Speed

1. High Accuracy: The LCR Benchtop Digital Bridge offers a remarkable 10.05% basic accuracy, ensuring precise measurements for capacitance, resistance, impedance, and inductance. 2. Quick Measuring Speed: With a maximum measuring speed of 200 times per second, this digital bridge enables efficient and rapid testing of various components. 3. Wide Frequency Range: The frequency measurement range spans from 10 Hz to 1 MHz, allowing continuous adjustable measurements with a step resolution as low as 1 mHz. 4. Adjustable Excitation Signal: The amplitude of the excitation signal can be easily adjusted from 10 mV to 2 V, with a fine step resolution of 1 mV. 5. Versatile Features: This LCR tester not only supports internal programmable DC bias voltage (-2V to +2V), but also allows for external DC bias voltage application (-60V to +60V). Additionally, it facilitates external current source connections and provides convenient monitoring of V and I testing signals.
