Key Digital HDMI over 70m CAT6 Extender Set with Power over CAT, HDMI Pass Thru, IR, RS-232 KD-X444LP

Extends 4K 18Gbps signals up to 230ft / 70m Supports 4K HDMI signals up to 18Gbps with HDR, HDCP 2.2, and surround audio up to Dolby® / DTS-HD 5.1 Kit includes a transmitter, receiver, power supply, IR emitter, and IR sensor Only requires a power supply on one unit Single CAT5e/6 UTP/STP Extension: Fully automatic equalization, and amplification depending on cabling length 4K Resolution Support: 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth) Flexible Power over CAT (PoC): Only one power connection is needed. Tx may power Rx, or Rx may power Tx Low Profile: Super slim chassis design Signal Extension: 4K/UHD (18G) up to 230ft / 70m with CAT5e/6, up to 328ft / 100m with CAT6A STP. 1080p up to 230 ft / 70m with CAT5e/6, up to 328ft / 100m with CAT6A STP IR Sensor: Sensor powering via +5V on IR In ports collects line-of-sight IR from remote(s) without external IR connecting block Up/Down IR: Two channels of IR enable control to/from devices or control systems connected to Tx and Rx units RS-232: Bi-Directional control to/from Tx and Rx unit on Phoenix connector Surround Audio Support: HDMI Pass-Thru supports Dolby®, Dolby® TrueHD, DTS™ and DTS-HD™ (formats up to 7.1); CAT6 Output supports Dolby®, DTS™ (formats up to 5.1/6.1)
