High Precision Economic Digital Force Gauge 30N 3Kg 65lb Digital Push-pull Force Meter Kilogram esting Machine Dynamometer -------- ,Accurate & Efficient Force Measurement

Purpose The SDF series Digital Force Gauge with compact size,high accuracy,they are easy to operate and handy to carry out,and can show the unit of newton and kilogram and Pound .The PEAK/TRACK knob of it can switch between the peak value load test and the continuous load test.They are excellent products which can take the place of the old style force gauges, and widely applied in electric,high &lowvoltageelectricappliance hardware,automobile parts,lighter and ignition system,light industry, mechanical,textile and so on industries for test of pull or push load test insertion force or pull and destructive experiment.Please reading the manual carefully before using this instrument. Please pause slightly when pressing the button to ensure the function of the button is running normally. (Model) NSDF-10 NSDF-20 NSDF-30 NSDF-50 NSDF-100 NSDF-200 NSDF-300 NSDF-500 (Peak load value) 10N 20N 30N 50N 100N 200N 300N 500N 1Kg 2Kg 3Kg 5Kg 10Kg 20Kg 30Kg 50Kg 2.2Ib 4.5Ib 6.5Ib 11Ib 22Ib 45Ib 65Ib 110Ib (Load ) When the indication value is less than 100 (integer position 2 digits and below), the load division value is 0.01; The indication value is higher than 100 (integer digit 3 digits) load division value of 0.1. (Accuracy) 1% Push-pull rod stroke 10mm (Power) 3V CR2032 environmental lithium battery (Battery Life) Six month (Working temperature) 5-35 (Transport temperature) -10-60 (Relative humidity) 15%-80%RH (Weight) 0.68Kg Related Products: dynamometer,force gauge,digital force gauge,force gauge push pull gauge,digital push-pull force gauge,tension meter,digital tension wire,digital dynamometer,elevator rope tension tester,textile tension meter,trigger pull gauge,grip strength trainer
