Datapath VisionSC-HD4+/H Quad-Port Capture Card (PCI express 2.1, 4x DisplayPort 1.1a)

High-performance capture card featuring a PCI express 2.1 bus interface that electronically supports x4, x8 and 16 lane widths. Equipped with four DisplayPort 1.1a outputs, each output delivers video up to 359 MP/s at 24bit (for example 2560 x 1600 at 60Hz). The card can be configured to convert the four outputs into two outputs, with each combined output supporting 3840 x 2160p at 30Hz. HDCP is supported when used with Datapath capture cards. DVI/HDMI connectivity is available through a range of DisplayPort cables and adaptors. Systems can integrate up to 13 cards within a single system.
