CELESTION T5931 Coax Mid 6.5-inch Cast Aluminum Chassis Ferrite Magnet Coaxial Driver Polyimide HF Diaphragm 8-Ohm 150 Watt Rms 300 Watt Max -FTX0617

FEATURES Brand : CELESTION Model Number : T5931 FTX0617 Ferrite magnet assembly acts as common motor for both LF and HF Polyimide HF diaphragm Demodulation ring 100 nominal HF coverage HF repair kit available SPECIFICATIONS Nominal diameter : 165mm / 6.5in Power rating : 150W Continuous power rating : 300W Rated impedance : 8 Sensitivity : 92dB Frequency range : 100-6000Hz Chassis type : Cast aluminum Magnet type : Ferrite Magnet weight : 0.88kg / 31oz SPECIFICATIONS Voice coil diameter : 44mm / 1.75in Voice coil material : Edgewound copper clad aluminium Former material : Glass fibre Cone material : Kevlar loaded paper Surround material : Cloth-sealed Suspension : Single Gap height Hg : 6mm / 0.24in VC winding height Hvc : 10mm / 0.4in PACKED DIMENSIONS & WEIGHT Single pack size W x D x H : 190mm x 190mm x 128mm / 7.4in x 7.4in x 5.0in Single pack weight : 3.5kg / 7.7lb Multi pack qty : 8 Multi pack size W x D x H : 350mm x 350mm x 240mm / 13.7in x 13.7in x 9.4in Multi pack weight : 30kg / 65lb MOUNTING INFORMATION Overall diameter : 189mm / 7.44in max Overall depth : 93mm / 3.7in Cut-out diameter : 150mm / 5.9in Mounting hole dimensions : 6.5x5.5mm / 0.26x0.22in Number of mounting holes : 4 Mounting hole PCD : 173.5mm / 6.83in Unit weight : 3kg / 6.6lb
