CAN2.0 to WiFi Converter Serial Server AP STA CANBUS ECAN-W01 TCP Gateway Heatbeat Isolation Protection Watchdog Two-Way Transparent Cloud Transmission

ECAN-W01 is a high-performance industrial WIFI and CAN bus data conversion equipment developed by EBT. It integrates two CAN bus interfaces, one EtherNet interface and one WiFi interface internally, which can easily complete the interworking of CAN bus network and WiFi network. ECAN-W01 has a built-in 120 ohm resistor, which can beenabled by dialing; Support the operation within the temperature range of - 40 ℃~85 ℃. ECAN-W01 has a 10M Ethernet interface. Customers can use the network cable to connect thePC end and enter the configuration software to configure the device parameters; The device WiFi network has two modes: AP and STA, which can quickly establish or access the WiFi network; High protection of CAN interface, increased isolation; 2-channel CAN port communication supports fixed common CAN baud rate and user-defined CAN baud rate, with the highest baud rate of 1Mbps; At the same time, the device has multiple working modes such as TCP Server, TCP Client, UDP, etc Integrated 2-way CAN bus interface, using plug-in terminal wiring mode;
