Analog-to-Digital Video Recorder — Composite RCA (Yellow/White/Red) to USB

Overview: Convert analog footage (for example, VHS) into digital files saved directly to a USB drive. This standalone unit accepts composite RCA video plus stereo audio and can output to a TV or monitor for preview. Inputs and connections: - VIDEO AUDIO IN: Composite RCA inputs for video and L/R audio from your source device. Yellow = video, white = audio left channel, red = audio right channel. The video source device should include the video cable, usually it is the 3RCA to 3RCA male cable or 3.5mm to 3RCA male video cable. - HDMI OUT: Use an HDMI cable to send live video to a TV or monitor for monitoring (HDMI cable is not included). - USB: Insert a USB flash drive to store the recorded video files directly to external storage. - DC power: Requires 5V DC power supplied via a USB-C to USB-A cable (power adapter is not included). Operation: - Record button: Press once to begin recording and press again to stop; the device will then save the file to the connected USB drive.
