AC/DC Switching Power Supply Adjustable 5V 12V 24V 36V 48V 60V 80V 120V 160V — 480W with Digital Display, Easy Operation

Overview: Adjustable AC/DC switching power supply with a clear digital display, rated at 480W for a variety of DC applications. Specifications: - Rated power: 480W - Product size: 21.5CM (length) * 11.5CM (width) * 5CM (height) - Output voltages: 5V, 12V, 24V, 36V, 48V, 60V, 80V, 120V, 160V (adjustable) - Output current: depends on the connected load and must not exceed the maximum rated output current Intended uses: Designed for a wide range of DC equipment including DC motor stepless speed control, LED stepless dimming, chemical electroplating speed regulation, laboratory testing and student experiments, among other applications. Important usage notes: When driving inductive loads (for example motors or fans), pay special attention to the motor starting current parameter — it must not exceed the power supply’s rated current. Exceeding that parameter can damage the power supply. In such cases, choose a power supply with a higher current rating or add soft-start protection for the motor. The circuit is designed to absorb the inrush current.
