Harmony Accessory Master F124 Ford Ranger sku-321842036

Harmony Accessory Master F124 is a Restored Automotive audio package for 1983-2012 Ford Ranger extended cab trucks, listed as sku-321842036, UPC 650785141902. It includes 1 custom dual 12" sealed subwoofer box for the rear floor pan, 2 Harmony Audio HA-F124 Flatline Series 12" subwoofers with single 4 ohm voice coils, 1 Kicker CX600.1 Class D mono amplifier (also identified as CXA8001 in the source title), and 1 Harmony Audio HA-AK8 8-gauge installation kit rated for 900 watt systems.

The box is also labeled for Ranger extended cabs 83-12. It holds two 12" subwoofers with a 6-1/4" mounting depth and gives each sub 1.97 cubic feet of air space. Its dimensions are 40" wide, 14-1/2" high, 11-3/4" deep at the top and 12-3/4" deep at the bottom. The jump seats cannot be used when the box is installed.

Each subwoofer is rated at 800 watts peak and 400 watts RMS, with 87.3dB sensitivity, a stated 25Hz-1.2Hz frequency response, a 4 1/2" mounting depth and an 11 1/8" cutout diameter. The amplifier delivers 300 watts x 1 channel at 4 ohms or 600 watts x 1 channel at 2 ohms, with 1200 watts x 1 channel maximum output and a 25-200 Hz frequency response. It measures 7-3/16"W x 8-1/8"D x 2-3/8"H.

The kit is included for installation.
