12-14X1 1/4 Unslotted Hex washer w/Bonded NEO EPDM Washer Self Drill #5 Point Full Thread Zinc (Pack Qty 1,500) BC-1220KWN5

A tapping screw with an integrally formed hex washer head, spaced threads, and a drill point significantly longer than that of a # 2 or #3 point drill screw. Beneath the head is a thin conically-shaped circular steel washer, bonded to a similarly shaped rubber-like piece which as a slightly smaller outside and inside diameter. When these washers are assembled (rubber side down) to self-piercing or self-drilling screws, those fasteners become “sealing screws”. Designed to drill through a greater thickness of steel than a standard self drilling screw. Although it can assist in attaching metal deck to structural steel, the #5 point self drilling screws are not structural bolts and should not be used as such. The neo-EPDM washer: (a) offers protection against leakage; (b) provides load bearing qualities superior to that of a regular flat washer; (c) reduces the chance of the fastening becoming loose due to vibration; (d) minimizes damage to the mating surface
