Use histogram bin planning to show a distribution

A histogram starts with a set of numerical observations, but its bars show counts inside intervals rather than the individual observations. For histogram bin planning, decide where those intervals begin, how wide they are, and which interval receives a value sitting exactly on a boundary before drawing anything. Then account for every value. The resulting picture can help a reader see how this particular set is grouped, provided the original numbers remain available for checking. For histogram bin planning, verify each step.

Consider twelve fictional objects, each with one recorded length in centimeters: 10, 11, 12, 12, 13, 14, 16, 17, 20, 20, 21, and 23. These are invented measurements for a manual exercise, not measurements of any listed product. The task is to make two honest groupings of the same twelve values. No value will be added, removed, or changed when the interval width changes.

Bar Chart Planning And The Different Work Of Numerical Intervals

For these lengths, the horizontal positions represent continuous stretches of a numerical scale. A decision about where one stretch ends determines where the next begins. A named-category comparison poses a different question: which name belongs to each count? The related guide to bar chart planning addresses that task. Here the names of objects do not determine the bars. Their recorded lengths and the chosen boundaries do.

Start the first plan at 10 centimeters, the smallest recorded value. Give each interval a width of 2 centimeters. The resulting intervals run from 10 to 12, 12 to 14, 14 to 16, 16 to 18, 18 to 20, 20 to 22, and 22 to 24. Each interval has the same width, and the next starts exactly where the preceding one ends. The last interval reaches beyond 23, so the entire set fits.

That list of intervals is incomplete until it says who owns each endpoint. Use a consistent convention: include the lower boundary and exclude the upper boundary. In words, “10 to under 12” includes 10 and 11 but excludes 12. “12 to under 14” includes both recorded 12s and 13 but excludes 14. Every interval follows the same rule, including the last one, which contains 23 because 23 is at least 22 and less than 24.

The shared boundary at 12 now has an unambiguous home. It is the end of the first interval, where it is excluded, and the start of the second, where it is included. The recorded 14 belongs to 14 to under 16, not to 12 to under 14. Both recorded 20s belong to 20 to under 22. State this convention alongside the finished graphic; labels such as “10–12” alone can leave a reader wondering whether 12 was counted twice.

Write the tally beside the interval list before drawing bars. From 10 to under 12 there are two values, 10 and 11. From 12 to under 14 there are three, 12, 12, and 13. From 14 to under 16 there is one, 14. From 16 to under 18 there are two, 16 and 17. From 18 to under 20 there are none. From 20 to under 22 there are three, 20, 20, and 21. From 22 to under 24 there is one, 23.

Keep the empty 18 to under 20 interval in the plan. Omitting it would make the neighboring occupied intervals appear adjacent and erase a visible gap in this particular grouping. On a histogram with equal-width intervals, each interval occupies the same horizontal width even if its count is zero. The gap reflects the chosen boundaries and the recorded values. It does not establish that lengths in that range are impossible outside this fictional set.

The tally reads 2, 3, 1, 2, 0, 3, 1. Add those counts and you get twelve, matching the number of recorded objects. This check catches some mistakes, but a matching total alone cannot prove that no value was counted twice while another was missed. For a small exercise, also trace each original value to its single interval. The duplicate 12s and duplicate 20s are separate observations, so each occurrence gets its own tally mark.

If a value lands on the final upper boundary in another dataset, extend the interval sequence rather than quietly changing the rule for the final bar. For example, under the stated convention a recorded 24 would belong to 24 to under 26, an additional interval of the same width. The present list stops at 23, so it needs no such interval. Writing the rule first makes this edge case easy to resolve without improvising after the tally.

Bar Chart Planning Aside: Audit A Second Equal-Width Grouping

Now use the original twelve measurements again, starting at 10 centimeters but giving each interval a width of 4 centimeters. The new intervals are 10 to under 14, 14 to under 18, 18 to under 22, and 22 to under 26. They still touch without overlapping, and the same lower-inclusive, upper-exclusive convention applies. Starting from the untouched measurement list matters: combining remembered bar heights from the first plan would hide which individual observations belong in the wider intervals.

In the second plan, 10, 11, 12, 12, and 13 fall in 10 to under 14, for a count of five. The values 14, 16, and 17 fall in 14 to under 18, for three. The values 20, 20, and 21 fall in 18 to under 22, also for three. The remaining 23 falls in 22 to under 26, for one. The second tally is therefore 5, 3, 3, 1. Its counts also add to twelve, and its intervals include every recorded value exactly once.

Notice what the width change does to the gap. The narrower plan has an empty interval from 18 to under 20. The wider plan puts that same unoccupied stretch inside 18 to under 22, alongside the two 20s and the 21. A reader looking only at the four wider bars cannot see that no recorded length lies between 18 and 20. The wider plan is not falsifying the data; it is answering at a coarser level of grouping. Keeping both interval definitions prevents a change in appearance from masquerading as a change in measurements.

The narrower plan separates the cluster around 12 and 13 from the one around 20 and 21 while leaving more space for individual interval-to-interval changes. The wider plan has fewer bars and combines values that the narrower plan kept apart. Neither view, on its own, establishes an underlying population shape. These are twelve invented values, and the height of a bar depends in part on the boundary choices. If a description says there is a gap, specify which interval plan reveals it.

There is a useful way to describe both results without treating either as the definitive picture: name the unit, the starting boundary, the interval width, and the endpoint convention before mentioning a bar height. For example, the narrow plan has three observations in 20 to under 22 centimeters. In the wider plan those same three observations sit in 18 to under 22 centimeters. The statement about the observations remains checkable because the source list stays visible.

A hand-drawn version can use equal horizontal space for each equal-width interval and vertical height for its count. Label the horizontal dimension in centimeters and the vertical dimension as a count of objects. Draw neighboring interval positions together, including the zero-count position in the narrow plan. The purpose here is to show the consequences of interval membership, not to claim that a drawing can recover detail already combined inside a bar.

Before sharing either drawing, read its interval labels against the written rule. Does the first interval include the lowest value? Does the final interval include the highest? Are the intervals contiguous and identical in width within each plan? Can someone reconstruct which interval receives 14 or 20 without asking you? Those questions test the bin decisions themselves. The twelve-value reconciliation checks the tally; the explicit endpoint rule checks its meaning.
